The 2713P-T10CD1 is a PLC PanelView 5310 operator terminal with a 10.4-inch color touch display, one 10/100Base-T Ethernet port and 24 V DC input.
Nhãn hiệu :
PLCmột phần số :
2713P-T10CD1Trọng lượng :
24 V DC nominal (18…30 V DC); verify firmware, network and panel cutoutKích thước :
252 × 297 × 69.5 mm; 0.79 kgnước xuất xứ :
10.4-inch SVGA touch display; one 10/100Base-T Ethernet portMã HS :
PanelView 5310 10.4-inch Operator TerminalSự mô tả :
The 2713P-T10CD1 is a PLC PanelView 5310 operator terminal with a 10.4-inch color touch display, 800 × 600 SVGA resolution, one 10/100Base-T Ethernet port and 24 V DC input.Click “+” to expand more specifications.
Source: Official publication 2713P-TD001 covers 2713P-T10CD1 technical specifications. Verify the terminal catalog number, supply, Ethernet connection, firmware and panel cutout before replacement.
2713P-T10CD1 identifies a PanelView 5310 operator terminal with a 10.4-inch color touch display, one 10/100Base-T Ethernet port and 24 V DC input.
2713P-T10CD1 uses a 10.4-inch SVGA TFT color display with 800 × 600 resolution and a resistive touchscreen rated for 1 million actuations.
2713P-T10CD1 provides one 10/100Base-T Ethernet port. Confirm the installed network settings, controller path and application configuration before commissioning.
2713P-T10CD1 uses 24 V DC nominal input within an 18…30 V DC range and includes 1 GB RAM and 1 GB user nonvolatile memory.
2713P-T10CD1 measures approximately 252 × 297 × 69.5 mm, weighs about 0.79 kg and uses an approximate the documented panel cutout for the installed enclosure.
2713P-T10CD1 requires confirmation of the complete catalog number, 24 V DC supply, Ethernet settings, firmware compatibility, application backup, panel cutout and enclosure rating before replacement.
2713P-T10CD1 inquiries should include the exact catalog number, series or revision, quantity, installed controller, application and firmware details, panel-cutout confirmation and clear nameplate photographs.
Official manufacturer-reference information for the 2713P-T10CD1 PanelView 5310 operator terminal.
Official publication 2713P-TD001 provides technical specifications for the 2713P-T10CD1 PanelView 5310 operator terminal.
OFFICIAL MANUALSend the complete model, quantity, nameplate photos and your technical or purchasing question.
Technical statements on this page are limited to official publication 2713P-TD001 and the exact-model operator-terminal documentation. No third-party product sources were used.
PLC is the product-family reference. 2713P-T10CD1 must be matched to the complete terminal label, installed application, 24 V DC supply, Ethernet settings, firmware and panel cutout.
Record the installed controller, 24 V DC supply, Ethernet connection, firmware revision and panel cutout.
Photograph the terminal label, power connector, communication wiring and panel mounting before removal.
Verify the 18…30 V DC input, Ethernet cabling and panel grounding before commissioning.
Do not select a substitute until the 9-inch display, touch input, Ethernet interface, supply, firmware and panel dimensions are confirmed.
Match 2713P-T10CD1 to the full terminal label and installed-system documentation.
Confirm the installed application, communication settings and machine state before terminal replacement.
Record the controller, 24 V DC supply, Ethernet settings, firmware and panel cutout.
Confirm the exact terminal catalog number, application file, supply, Ethernet settings, firmware and panel mounting before commissioning.
A clear workflow for sourcing, verification, shipment preparation, delivery and product assurance.
Include the complete part number, quantity and delivery destination.
