The 2711P-T9W22D9P is a PanelView Plus 7 Performance terminal with a 9-inch widescreen resistive-touch display, 800 x 480 WVGA resolution, dual 10/100Base-T Ethernet ports and 24 V DC input.
Nhãn hiệu :
PLCmột phần số :
2711P-T9W22D9PKích thước :
190 mm x 280 mm x 69.6 mm (H x W x D); 1.58 kg approx.Mã HS :
PanelView Plus 7 Performance TerminalSự mô tả :
The 2711P-T9W22D9P is a 9-inch widescreen analog resistive-touch PanelView Plus 7 Performance terminal with 800 x 480 WVGA resolution, dual 10/100Base-T Ethernet ports and 24 V DC input.Click “+” to expand more specifications.
Source: Official publication 2711P-TD009 lists 2711P-T9W22D9P and supports the display, power, connectivity, dimensions, cutout and environmental data shown here.
2711P-T9W22D9P is a PanelView Plus 7 Performance terminal for operator visualization and touch control in industrial automation systems.
2711P-T9W22D9P uses a 9-inch widescreen color TFT LCD with 800 x 480 WVGA resolution and analog resistive touch input.
2711P-T9W22D9P uses a 24 V DC nominal supply and two 10/100Base-T Ethernet ports supporting DLR, linear or star topologies.
2711P-T9W22D9P has a 196 x 118 mm viewing area and requires a 162 x 252 mm panel cutout.
2711P-T9W22D9P is panel mounted and is specified for operation from 0 to 55 °C.
2711P-T9W22D9P measures 190 mm high, 280 mm wide and 69.6 mm overall depth, with an approximate weight of 1.58 kg.
For 2711P-T9W22D9P, provide the complete catalog number, quantity, panel cutout, power supply, Ethernet topology, connected controller and application requirements.
Official manufacturer-reference information for the 2711P-T9W22D9P PanelView Plus 7 Performance terminal.
Official publication 2711P-TD009 lists 2711P-T9W22D9P and documents its display, power, connectivity, dimensions, cutout and environmental specifications.
OPEN OFFICIAL TECHNICAL DATA PDFSend the complete model, quantity, nameplate photos and your technical or purchasing question.
Technical statements on this product page are limited to official publication 2711P-TD009 and the exact official product record for 2711P-T9W22D9P.
2711P identifies the PanelView Plus 7 Performance terminal family; T identifies touch input; 9W identifies the 9-inch widescreen display; 22 identifies the dual-Ethernet configuration; and D identifies 24 V DC power.
PanelView Plus 7 Performance terminal.
Analog resistive touch input.
9-inch widescreen color display.
Two 10/100Base-T Ethernet ports supporting DLR, linear or star topologies.
24 V DC nominal input, 18...30 V DC operating range.
Two 10/100Base-T Ethernet ports supporting DLR, linear or star topologies.
162 x 252 mm panel cutout and 196 x 118 mm viewing area.
The terminal presents machine status, commands and production information on a 9-inch widescreen touch display.
Touch input and dual Ethernet connectivity support operator control along production lines.
The color TFT display supports process status, alarm and diagnostic visualization.
The panel-mounted terminal is used in suitably protected industrial control panels.
A clear workflow for sourcing, verification, shipment preparation, delivery and product assurance.
Include the complete part number, quantity and delivery destination.
