The OMRON NX-PNC202 is an NX-series PROFINET Coupler Unit to bridge OMRON’s modular NX-series with a PROFINET network. It functions as a standard PROFINET IO Device (slave node), enabling third-party PROFINET masters to control OMRON NX-series I/O modules directly.
Nhãn hiệu :
OMRONmột phần số :
NX-PNC202Trọng lượng :
0.15 kgKích thước :
4.6cm x 10.0cm x 7.1cmnước xuất xứ :
JAPANMã HS :
8537101190Sự mô tả :
PROFINET coupler linking NX-series I/O units to industrial Ethernet networks.
The OMRON NX-PNC202 is an NX-series PROFINET Coupler Unit designed to connect NX I/O modules to an open PROFINET RT industrial network. It works as a PROFINET IO Device, exchanging I/O data between a PROFINET IO Controller and up to 63 NX Units. With dual RJ45 ports, 24 VDC power input, USB setup access, and compact DIN-rail mounting, it is suitable for decentralized machine control and plant automation systems.
|
Contact Sales Manager Nina |
Whatsapp：+86 18030235312 |
|
Email：sales8@askplc.com |
|
Technical Parameters |
|
|
Part Number |
NX-PNC202 |
|
Product Series |
OMRON NX Series |
|
Product Type |
PROFINET Coupler Unit |
|
PROFINET Version |
2.41 |
|
PROFINET Unit Type |
PROFINET IO Device |
|
Number of Connectable NX Units |
63 units max |
|
NX Bus I/O Data Size |
Input: up to 512 bytes; Output: up to 512 bytes |
|
Ethernet Interface |
2 x RJ45 ports, 100 Mbps, full-duplex, auto-negotiate |
|
Power Supply Voltage |
24 VDC, 20.4 to 28.8 VDC |
|
Weight and Dimension |
0.15 kg max; 4.6cm x 10.0cm x 7.1cm |
|
FAQ |
|
Q1: What is the main function of the NX-PNC202? |
|
A: NX-PNC202 links an OMRON NX I/O terminal to a PROFINET network. It collects I/O data from connected NX Units and exchanges that data with a PROFINET IO Controller as one PROFINET IO Device. |
|
|
|
Q2: Can NX-PNC202 work with third-party PROFINET controllers? |
|
A: Yes. It is designed for PROFINET multivendor networks. Configuration normally requires the correct GSDML file, compatible PROFINET controller software, and proper I/O mapping for the connected NX Units. |
|
|
|
Q3: How many NX I/O modules can be connected to one NX-PNC202? |
|
A: Up to 63 NX Units can be connected. However, the final configuration must also consider I/O data size, power supply capacity, installation orientation, ambient temperature, and the supported NX Unit list. |
|
|
|
Q4: What should be checked before replacing an NX-PNC202? |
|
A: Check the PROFINET device name, IP settings, GSDML version, power supply rating, and Sysmac Studio configuration before installing a replacement unit. |
Application Fields
Oil and gas wellhead monitoring skids
Natural gas compressor station control panels
Water and wastewater pump station automation
Power plant auxiliary equipment control
|
