Honeywell DC1010CR-101000-E DC1000 RTD Digital Temperature Controller

DC1010CR-101000-E identifies a Honeywell DC1000 series 48 × 48 mm (1/16 DIN) digital temperature controller for 90–240 VAC power, without a programmer, and with an RTD input.

The DC1010CR-101000-E model code specifies an RTD input. Confirm the installed RTD type, measuring range and wiring arrangement against the Honeywell manual before commissioning or replacement.

DC1010CR-101000-E specifies a relay for Output 1, no Output 2 and one alarm output. The Output 1 relay is SPDT and rated 3 A at 240 VAC; verify the connected load and wiring before replacement.

DC1010CR-101000-E uses dual four-digit LED displays with a ten-segment bargraph and status indicators. The DC1000 platform supports PID and ON/OFF control, autotuning, a 250 ms process-value sample time, 14-bit input resolution and ±0.2% full-scale accuracy.

The code in DC1010CR-101000-E specifies a 90–240 VAC supply. Honeywell lists an operating range of 0 to 50 °C and 50–85% relative humidity, non-condensing; confirm cabinet conditions and supply voltage before installation.

DC1010CR-101000-E is the 48 × 48 mm (1/16 DIN) DC1010 format. Confirm the panel cutout, mounting depth, terminal access and ventilation clearance against the Honeywell installation drawing.

For DC1010CR-101000-E, provide the complete model code, RTD sensor type and wiring, supply voltage, relay and alarm load details, panel cutout, retained PID settings, quantity and destination. Match every suffix character before approving a replacement.
