Honeywell 2MLF-RD4A Temperature Input Module

Basic Information

Model Number: 2MLF-RD4A

Manufacturer: Honeywell
Product Name: Temperature Input Module
Availability: In Stock
Product Origin: USA
Shipping Port: Xiamen, China

Condition: 100% Original

Warranty: 1 Year

Input Channels: 4, 3-wire (4-wire compatible)
Display Resolution: 0.1°C
Conversion Speed: 40 ms/channel (sequential conversion)
System Accuracy: ±0.2% F.S. (@25°C); ±0.3% F.S. (0–55°C)
Temperature Coefficient: ±5 ppm/°C (typical)
Data Format: 16-bit signed (-32768 to 32767) or programmable from 0 to 65535
Filtering/Averaging: Digital 160–64000 ms; selectable time averaging, count averaging, and moving averaging.
Diagnostic functions: Wire break detection, process alarm, input rate-of-change alarm, and maximum/minimum value recording.
Isolation: Optocoupler isolation between channels and PLC power supply; non-isolated between channels.
Isolation withstand voltage: AC 560 V rms / 3 cycles (at an altitude of 2000 m).
Backplane 5 V consumption: 450 mA.
External power supply: No external power supply required.
Operating temperature: -25 … +70°C (-25 … +70°C)
Storage temperature: -40 … +85°C (-40 … +85°C)
Relative humidity: 5–95% RH (non-condensing).
Connection: 18-position removable screw terminal block (M3 x 6).
Applicable wire: 0.3–0.75 mm² stranded wire.
Mounting method: 35 mm DIN rail
