B&R X20AO2632 2-Channel 16-Bit Analog Output Module

Claim Your Extra Discount: Contact Sales Nina Lan for Details

Email：sales8@askplc.com

Mobile(WhatsApp)：+86 18030235312

The B&R X20AO2632 is a compact X20 analog output module for applications that need accurate voltage or current setpoints. It provides two independently configurable channels, each supporting ±10 V or 0–20 mA output with 16-bit converter resolution. NetTime technology enables synchronized time-based shutdown events, while output protection, diagnostic feedback, and 500 V bus isolation support reliable machine and process control. The module is suited to compact distributed I/O assemblies using B&R X20 bus modules and terminal blocks.

FAQ

Q1: Can the two output channels use different signal types?
A: Yes. Each channel can be configured independently for ±10 V voltage or 0–20 mA current output.

Q2: What is the advantage of the NetTime function?
A: It enables synchronized output shutdown at a defined time with microsecond-level timing precision.

Q3: What happens when the validation timer expires?
A: The affected output switches off and resets until a new valid timestamp is transmitted.

Q4: Why must field-load limits be checked before installation?
A: Voltage outputs require loads of at least 1 kΩ, while current outputs support up to 600 Ω on newer revisions.
