Digital Input Sequence of Events, Coated
Nhãn hiệu :
Honeywellmột phần số :
8C-PDISA1 51454471-276Trọng lượng :
0.3 kgKích thước :
6x15.2x14.3cmnước xuất xứ :
USAMã HS :
8537101190Sự mô tả :
Digital Input Model
Basic Information
Part number
8C-PDISA1 51454471-276
Origin
USA
Manufacturer
Honeywell
Status
Brand New
Description
Digital Input Model
Payment
T/T
Product Description
The 8C-PDISA1 is a Series 8 Digital Input Sequence of Events (SOE) module for the Honeywell Experion C300 controller. It accepts 24 VDC discrete signals and provides time-tagging of input state changes with 1 ms resolution for sequence of events recording. The module supports three modes of operation: Normal (20 ms PV scan), SOE (1 ms resolution, 20 ms PV scan), and Low Latency (5 ms PV scan). It features extensive internal diagnostics, optional redundancy, galvanic isolation, and on-board excitation power (internal or external field power selection). The module plugs into a Series 8 IOTA (8C-TDILA1 for non-redundant, 8C-TDILB1 for redundant) and is conformally coated for harsh environments.
Product Specification
Model Number:8C-PDISA1
Description:Digital Input Sequence of Events, Coated
Input Channels:32
Voltage Rating:24 VDC
DI Power Voltage Range:18 to 30 VDC
Module Current Rating:95 mA
Input Channel Scanning (PV):Normal = 20 ms; Fast = 5 ms
SOE Resolution:1 ms
ON Sense Voltage/Current:13 VDC (min) or 3 mA (min)
OFF Sense Voltage/Current:5 VDC (max) or 1.2 mA (max)
Input Impedance:4.2 kΩ
Absolute Delay (Input Filter + Isolation):5 ms ± 20%
Field Resistance for Guaranteed ON:300 Ω max @ 15 VDC
Field Resistance for Guaranteed OFF:30 kΩ min @ 30 VDC
-------------------------------------------------------------
RFQ--please contact sales manager Frida Zhang
Email: sales5@mooreplc.com
Phone/ Whatsapp: +86 15359408275
